| System |
CPU |
Gen.6th Intel® Skylake-U Celeron 3855U; Core I3-6100U; I5-6200U; I7-6500U CPU Gen. 7th Intel® Kabylake-U Celeron 3865U; Core I3-7100U; I5-7200U; I7-7500U CPU |
| Chipset |
Intel® SOC |
| System Wemory |
1*DDR4 2133 MHz SODIMM, Max 16GB |
| BIOS |
Insyde SPI 64Mbit flash |
| Storage |
1*2.5” SATA HDD bay, support SATA3.0 6Gbps HDD/SSD, 1*mSATA |
| Display |
17.0” LED backlight TFT LCD and HDWI(4K resolution) , dual display, Intel® HD graphics 510/520 |
| Touch |
5 wire resistive touch optional projected capacitive touch, USB control |
| Expansion |
1*Mini PCIe(PCIe&USB signal) |
| Audio |
Realtek ALC662VD controller, Support 5.1 channel, 2*3W Speaker |
| Real I/O |
2*COM: 2*RS232/422/485, DB9，Opt. 2*RS232,DB9,3-wire signal 1*HDMI,1*Line out |
| 4*USB3.0 Type A |
| 2*RJ45 |
| Front I/O |
1*USB2.0 Type A |
| LAN |
2*Intel I210AT PCIe Gig. Ethernet, 10/100/1000Mbps |
| Control SW/LED |
1*Cmos, 1*AT/ATX, Power button, 2–pin connecter with power switch signal,HDD LED |
| Power Supply |
DC to DC: 9~36V input, consumption: TDP 12V/2.95A(Intel® I5–6200U CPU, 4GB DDR4) |
| OS |
Windows 7, Windows 8.1,Windows 10,Linux |
| Mechanical & Environmental |
Construction |
Aluminum die–casting front bezel , fin–shaped radiator shell |
| Operating Temperature |
0~50℃ –HDD( –10~55℃ –SSD), with airflow |
| Storage |
–20~60℃ |
| Temperature |
| Storage Humidty |
10~95%@40 , non–condensing |
| Shock |
10g peak acceleration(duration 11ms), in operating with HDD |
| Vibration |
1g 5~500Hz, in operating with HDD |
| Mounting |
Panel mounting, VESA 100*100, Rack mounting |
|
| Dimension |
(W*H*D):415.5*360.5*59mm; mounting cut out(W*H): 407*352mm |
| Net Weight |
6.1kg |
|
| EMC |
CE,FCC Class A |
| LCD |
Type |
17.0‘’ TFT LED |
| Resolution |
1280*1024 |
| Color |
16.2M colors |
| Pixel Pitch(mm) |
0.297*0.297 |
| Brightness (cd/m2) |
350 |
| Viewing Angle |
80 Degree（left）, 80 Degree（right）, 80 Degree（up）, 80 Degree（down） |
| Operating Temperature |
-20~70°C |
| Backlight Lifetime |
50,000 hours |
| Touch |
Type |
5 wire resistive touch |
Projected capacitive touch |
| Resolution |
gapless |
gapless |
| Light Transmittance |
83% |
90% |
| Interface |
USB |
USB |
| Consumption |
+5V @ 200mA |
+5V @ 300mA |
| OS |
Windows/ Linux |
Windows/ Linux |
| Click Lifetime |
35 million times |
3 billion times |
