Facts
General description
| Part number | WE185 000 108 |
| Life cycle status | Active |
| Warranty | 3 years |
Certifications
| General | CE |
| Marine | DNV GL, IEC 60945, IEC 61174 (ECDIS), IEC 60936 (radar) |
Mechanical
| Mechanical size | 448.4 (W) x 272.6 (H) x 78 (D) mm |
| Mounting option | Flush mount |
| Touch type | No |
| Cut-out size | Depends on selected mounting option, see datasheets |
| Weight | 6.4 kg |
| Housing material | RAL 9005 fine structure |
Power
| Input voltage | 90-264 VAC (IEC inlet) |
| Power consumption (max) | 25W |
Display
| Size diagonal | 18,5″ diagonal |
| Resolution | 1920 x 1080 pixels |
| Backlight | LED backlight |
| Backlight life time | 50000 hours |
| Backlight brightness | 350 cd/m2 |
| Backlight dimming | Marine optimized dimming, 0 – 100% |
| Display type | TFT-LCD with LED backlight |
